SkyWalking(更新中)
SkyWalking
撰写本文时, 基于当时最新版: SkyWalking_8.6.0, ElasticSearch_7.13.1, 版本编写.
SkyWalking: an APM(application performance monitor) system, especially designed for microservices, cloud native and container-based architectures.
1) 链路追踪
分布式架构给我们带来了很多优势, 当然也带来了一些麻烦:
- 无法直接排查并发量高的服务节点, 难点.
- 生产环境的异常排查以及解决, 方案有 ELK 等.
- 服务器流量统计, 方案较多, Prometheus 相关的 NodeExporter 比较流行.
1.1) Dapper
2010 年 Google 发布了介绍其分布式监控系统 Dapper 的论文: 《Dapper, a Large-Scale Distributed Systems Tracing Infrastructure》, (中文版), 之后诞生的很多 APM 监控系统都参考了 Dapper 的实现.
1.2) OpenTracing
由于 Google Dapper 仅仅在 Google 内部使用, 论文发布后, 诞生了很多类似的 APM 系统, 但一直缺少一个比较统一的标准, 所以 OpenTracing 诞生了, 它提供了一套标准以及各种主流语言的 API 接口供于实现, 包括本文的主题 Skywalking 也是基于其标准实现的.
1.3) APM 系统三要素
2017 年, 分布式追踪峰会产生了另一篇比较有名的文章:《Metrics, tracing, and logging》 , 我们可以称之为 APM 系统三要素, 通过其三要素, 来解决分布式系统带来的一些麻烦, 我们可以简单了解一下:
- Logging: 记录系统行为的离散事件, 如我们可以通过 ELK 记录业务处理中的 Error Log, 分析其行为. 但 Log 一般比较离散.
- Metrics: 记录系统各个时刻的各种指标, 即各种监控, 如我们可以通过 Promethus 记录系统服务在各个时间节点的 QPS, 统计服务在各个时刻的负载.
- Tracing: 记录用户访问系统的一些特征, 如在 MicroService 中服务上下游调用的链路, 即记录用户请求被那些服务处理, 服务间的调用顺序等.
2) OpenTracing
从 2016 年以来, OpenTracing 基本成为了行业的标准, 我们先了解一下它. OpenTracing 定义了三种相互关联的类型: Tracer, Span 和 SpanContext.
2.1) Tracer
Tracer 可以创建 Spans, 可以理解为客户端一次请求的会话, 其大概有以下功能:
- Start a new Span
- Inject a SpanContext into a carrier
- Extract a SpanContext from a carrier
2.2) Span
Span 与 Tracer 相关联, 代表我们分布式系统中的请求处理节点, 一次 Tracer 会话可能关联多个 Span, 其大概有以下功能:
- Retrieve the Spans SpanContext
- Overwrite the operation name
- Finish the Span
- Set a Span tag: Tag 不会传递到下一个 Span, 通常用来记录并存储业务相关数据.
- Log structured data:
- Set a baggage item: Baggage 即在一个 Tracer 中, 可以跨 Span 向下级 Span 传递的数据.
- Get a baggage item
2.3) SpanContext
SpanContext 主要用于封装 Baggage, 在 Span 上级往下级传递数据时使用, 也就是意义上的上下文.
3) 主流开源 APM
- CAT: 美团开源, 侵入性大, Java 实现.
- Zipkin: Twitter 开源, 低侵入, Java 实现, 支持部分 OpenTracing.
- Pinpoint: 韩国开源, 零侵入, Java 实现.
- SkyWalking: 中国开源, 零侵入, Java 实现, 完全支持 OpenTracing 标准.
4) SkyWalking 简介
可以先从官方演示链接, 预览一下其 UI 效果: http://demo.skywalking.apache.org, 账号密码都为: skywalking
接着再上一张官网的结构图：
SkyWalking 总体上分为四个部分：
- Probes: 即探针, 也叫 Agent, 负责采集数据, 并将数据上报至 OAP.
- OAP: SkyWalking 的后端服务, 负责接收探针上报的数据, 聚合分析处理后, 存储至 Storage 中; 且向 UI 提供数据查看接口.
- Storage: 数据持久化仓库, 可以自行挑选实现如: ES, MySQL, H2, TiDB 等.
- UI: SkyWalking 还提供了一套官方的可视化界面供于查看监控各数据.
5) SkyWalking 安装
安装 SkyWalking 步骤大概如下, 本文都将其相关应用安装部署在 Docker 上:
-
- 安装 Storage, 用于存储我们的监控数据, 提供查询, 示例使用 ES 作为我们是 Storage 实现, 本文使用 7.13.1 版本演示.
-
- 安装 OAP 后端, 本文使用 8.6.0 版本演示.
-
- 安装 SkyWalking UI 前端, 本文使用与 OAP 配套的 8.6.0 演示.
5.1) SkyWalking Storage 安装
本文以单节点做演示.
docker run --name elasticsearch -p 9200:9200 -p 9300:9300 -e "discovery.type=single-node" docker.elastic.co/elasticsearch/elasticsearch:7.13.15.2) SkyWalking OAP 后端安装
请将 SW_STORAGE_ES_CLUSTER_NODES 替换为对应 ES 的容器 Name 以及端口.
$ docker run --name skywalking-oap --restart always -d -e SW_STORAGE=elasticsearch7 -e SW_STORAGE_ES_CLUSTER_NODES=elasticsearch:9200 apache/skywalking-oap-server:8.6.0-es75.3) SkyWalking UI 安装
安装 SkyWalking-UI 时, 请注意其版本与 OAP 是否相互对应, 在撰写本文时, OAP 与其对应的 UI, 版本号相同一一对应.
且将 SW_OAP_ADDRESS 替换为对应 OAP 的容器 Name 以及端口.
$ docker run --name skywalking-ui --restart always -d -e SW_OAP_ADDRESS=skywalking-oap:12800 apache/skywalking-ui:8.6.05.4) WkyWalking Server 配置
安装完以上三项后, 需要对 OAP 后端进行配置, 以适应我们项目中不同的技术(如 Nacos, Dubbo, Eureka).
- 进入容器:
docker exec -it skywalking-oap bash
9) 参考文献
以下排名不分先后:
- https://storage.googleapis.com/pub-tools-public-publication-data/pdf/36356.pdf (Dapper, a Large-Scale Distributed Systems Tracing Infrastructure)
- https://bigbully.github.io/Dapper-translation/ (Dapper-translation)
- https://peter.bourgon.org/blog/2017/02/21/metrics-tracing-and-logging.html (Metrics, tracing, and logging)
- https://zhuanlan.zhihu.com/p/28075841 (Logging,Metrics 和 Tracing)
- https://opentracing.io/specification/ (The OpenTracing Semantic Specification)
JVM(更新中)
JVM(更新中)
本文基于 JDK 8 HotSpot VM 撰写
1) Java 概述
1.1) JAVA 版本历史
图来转自 WikiPedia(https://zh.wikipedia.org/wiki/Java版本歷史)
1.2) JVM LTS Version / GC 选型
- JDK 8: 默认使用 Parallel Scavenge + Parallel Old, 配置充裕建议使用 G1
- JDK 11: 默认使用 G1, 配置充裕建议使用 ZGC
- JDK 17: 未发布
1.2) 主流开源 JVM 选型
2) JVM 结构
我们先来看看整体的结构:
2.1) 虚拟机栈
2.2) 方法区
方法区的存储结构比较复杂, 一部分在堆中, 一部分在元空间中
2.3) 堆
堆中的 Young Gen / Old Gen 存于 JVM 虚拟内存中, Metspace 直接使用 本地内存(默认无限扩容).
2.3.1) 堆默认分配大小
- 初始堆大小: 物理内存的 1 / 64
- 最大堆大小: 物理内存的 1 / 4, 最大为 1G
2.3.2) 垃圾回收过程
Eureka Client 源码
Eureka Client 源码
本文采用知识共享 署名-相同方式共享 4.0 国际 许可协议进行许可。
访问 https://creativecommons.org/licenses/by-sa/4.0/ 查看该许可协议。
本文基于上游最新 RELEASE 版, SpringBoot 2.2.5, SpringCloud Hoxton.SR8 撰写, 发现 EurekaClient 的源码变动幅度还是有点大的.
1) Eureka Client 启动流程
通常我们的 Eureka Client 是以 SpringBoot 的 Starter 引入的, 如: spring-cloud-starter-netflix-eureka-client.
那么一个正常的 Starter 依赖, 会遵循 SpringBoot 自动装配的原则, 在 spring.factories 中定义对应的 AutoConfiguration 自动装配类, 那我们就从这里开始找吧~
在 spring-cloud-netflix-eureka-client 依赖中找到 spring.factories 文件, 打开康康:
org.springframework.boot.autoconfigure.EnableAutoConfiguration=\
org.springframework.cloud.netflix.eureka.config.EurekaClientConfigServerAutoConfiguration,\
org.springframework.cloud.netflix.eureka.config.DiscoveryClientOptionalArgsConfiguration,\
org.springframework.cloud.netflix.eureka.EurekaClientAutoConfiguration,\
org.springframework.cloud.netflix.ribbon.eureka.RibbonEurekaAutoConfiguration,\
org.springframework.cloud.netflix.eureka.EurekaDiscoveryClientConfiguration,\
org.springframework.cloud.netflix.eureka.reactive.EurekaReactiveDiscoveryClientConfiguration,\
org.springframework.cloud.netflix.eureka.loadbalancer.LoadBalancerEurekaAutoConfiguration
org.springframework.cloud.bootstrap.BootstrapConfiguration=\
org.springframework.cloud.netflix.eureka.config.EurekaConfigServerBootstrapConfiguration我几乎把他们全看了一遍, 核心自动装配类为: EurekaClientAutoConfiguration, 我们只关注他就好了.
1.1) EurekaClientAutoConfiguration 注解分析
@Configuration(proxyBeanMethods = false) // 1. 配置类, 关闭 Bean 代理
@EnableConfigurationProperties // 2. 注入 SpringBoot 配置
@ConditionalOnClass(EurekaClientConfig.class)
@ConditionalOnProperty(value = "eureka.client.enabled", matchIfMissing = true) // 3. 默认开启自动装配
@ConditionalOnDiscoveryEnabled
@AutoConfigureBefore({ NoopDiscoveryClientAutoConfiguration.class,
CommonsClientAutoConfiguration.class, ServiceRegistryAutoConfiguration.class })
@AutoConfigureAfter(name = {
"org.springframework.cloud.netflix.eureka.config.DiscoveryClientOptionalArgsConfiguration", // 额外的可选参数自动配置
"org.springframework.cloud.autoconfigure.RefreshAutoConfiguration", // 动态刷新 Config 相关
// 内部定义了个刷新监听器有兴趣可以看看 -> EurekaClientConfigurationRefresher
"org.springframework.cloud.netflix.eureka.EurekaDiscoveryClientConfiguration",
// 自动服务注册配置(以前用来更新上报服务状态, 好似已弃用)
"org.springframework.cloud.client.serviceregistry.AutoServiceRegistrationAutoConfiguration" })
public class EurekaClientAutoConfiguration {我们接着往下看, 看一下重点的方法:
1.2) EurekaClientAutoConfiguration 源码分析
-
eurekaClient: 初始化 Eureka Client 实例
org.springframework.cloud.netflix.eureka.EurekaClientAutoConfiguration.EurekaClientConfiguration#eurekaClient@Bean(destroyMethod = "shutdown") @ConditionalOnMissingBean(value = EurekaClient.class, search = SearchStrategy.CURRENT) public EurekaClient eurekaClient(ApplicationInfoManager manager, EurekaClientConfig config) { return new CloudEurekaClient(manager, config, this.optionalArgs, this.context); }往构造方法中走走看:
org.springframework.cloud.netflix.eureka.CloudEurekaClient#CloudEurekaClientpublic CloudEurekaClient(ApplicationInfoManager applicationInfoManager, EurekaClientConfig config, AbstractDiscoveryClientOptionalArgs<?> args, ApplicationEventPublisher publisher) { super(applicationInfoManager, config, args); this.applicationInfoManager = applicationInfoManager; // 注册所需信息类注入 this.publisher = publisher; this.eurekaTransportField = ReflectionUtils.findField(DiscoveryClient.class, "eurekaTransport"); ReflectionUtils.makeAccessible(this.eurekaTransportField); }注入了一下注册所需的信息, 进入父类构造康康:
com.netflix.discovery.DiscoveryClient#DiscoveryClientpublic DiscoveryClient(ApplicationInfoManager applicationInfoManager, final EurekaClientConfig config, AbstractDiscoveryClientOptionalArgs args) { this(applicationInfoManager, config, args, ResolverUtils::randomize); } public DiscoveryClient(ApplicationInfoManager applicationInfoManager, final EurekaClientConfig config, AbstractDiscoveryClientOptionalArgs args, EndpointRandomizer randomizer) { // 1. 这边继续掉了一个重载方法 this(applicationInfoManager, config, args, new Provider<BackupRegistry>() { // 这里实际上实现了一个回调, 当访问不到默认 server 的时候, 回调到这个备份节点 // **需要配置** private volatile BackupRegistry backupRegistryInstance; @Override public synchronized BackupRegistry get() { if (backupRegistryInstance == null) { String backupRegistryClassName = config.getBackupRegistryImpl(); if (null != backupRegistryClassName) { try { backupRegistryInstance = (BackupRegistry) Class.forName(backupRegistryClassName).newInstance(); logger.info("Enabled backup registry of type {}", backupRegistryInstance.getClass()); } catch (InstantiationException e) { logger.error("Error instantiating BackupRegistry.", e); } catch (IllegalAccessException e) { logger.error("Error instantiating BackupRegistry.", e); } catch (ClassNotFoundException e) { logger.error("Error instantiating BackupRegistry.", e); } } if (backupRegistryInstance == null) { logger.warn("Using default backup registry implementation which does not do anything."); backupRegistryInstance = new NotImplementedRegistryImpl(); } } return backupRegistryInstance; } }, randomizer); } @Inject DiscoveryClient(ApplicationInfoManager applicationInfoManager, EurekaClientConfig config, AbstractDiscoveryClientOptionalArgs args, Provider<BackupRegistry> backupRegistryProvider, EndpointRandomizer endpointRandomizer) { // 2. 校验和引用, 略过 if (args != null) { this.healthCheckHandlerProvider = args.healthCheckHandlerProvider; this.healthCheckCallbackProvider = args.healthCheckCallbackProvider; this.eventListeners.addAll(args.getEventListeners()); this.preRegistrationHandler = args.preRegistrationHandler; } else { this.healthCheckCallbackProvider = null; this.healthCheckHandlerProvider = null; this.preRegistrationHandler = null; } this.applicationInfoManager = applicationInfoManager; InstanceInfo myInfo = applicationInfoManager.getInfo(); clientConfig = config; staticClientConfig = clientConfig; transportConfig = config.getTransportConfig(); instanceInfo = myInfo; if (myInfo != null) { appPathIdentifier = instanceInfo.getAppName() + "/" + instanceInfo.getId(); } else { logger.warn("Setting instanceInfo to a passed in null value"); } this.backupRegistryProvider = backupRegistryProvider; this.endpointRandomizer = endpointRandomizer; this.urlRandomizer = new EndpointUtils.InstanceInfoBasedUrlRandomizer(instanceInfo); localRegionApps.set(new Applications()); fetchRegistryGeneration = new AtomicLong(0); remoteRegionsToFetch = new AtomicReference<String>(clientConfig.fetchRegistryForRemoteRegions()); remoteRegionsRef = new AtomicReference<>(remoteRegionsToFetch.get() == null ? null : remoteRegionsToFetch.get().split(",")); if (config.shouldFetchRegistry()) { this.registryStalenessMonitor = new ThresholdLevelsMetric(this, METRIC_REGISTRY_PREFIX + "lastUpdateSec_", new long[]{15L, 30L, 60L, 120L, 240L, 480L}); } else { this.registryStalenessMonitor = ThresholdLevelsMetric.NO_OP_METRIC; } if (config.shouldRegisterWithEureka()) { this.heartbeatStalenessMonitor = new ThresholdLevelsMetric(this, METRIC_REGISTRATION_PREFIX + "lastHeartbeatSec_", new long[]{15L, 30L, 60L, 120L, 240L, 480L}); } else { this.heartbeatStalenessMonitor = ThresholdLevelsMetric.NO_OP_METRIC; } logger.info("Initializing Eureka in region {}", clientConfig.getRegion()); // 3. 如果同时关闭了 register-with-eureka 和 fetch-registry, return 掉 if (!config.shouldRegisterWithEureka() && !config.shouldFetchRegistry()) { logger.info("Client configured to neither register nor query for data."); scheduler = null; heartbeatExecutor = null; cacheRefreshExecutor = null; eurekaTransport = null; instanceRegionChecker = new InstanceRegionChecker(new PropertyBasedAzToRegionMapper(config), clientConfig.getRegion()); // This is a bit of hack to allow for existing code using DiscoveryManager.getInstance() // to work with DI'd DiscoveryClient DiscoveryManager.getInstance().setDiscoveryClient(this); DiscoveryManager.getInstance().setEurekaClientConfig(config); initTimestampMs = System.currentTimeMillis(); initRegistrySize = this.getApplications().size(); registrySize = initRegistrySize; logger.info("Discovery Client initialized at timestamp {} with initial instances count: {}", initTimestampMs, initRegistrySize); return; // no need to setup up an network tasks and we are done } // 4. 一些线程池创建 try { // default size of 2 - 1 each for heartbeat and cacheRefresh scheduler = Executors.newScheduledThreadPool(2, new ThreadFactoryBuilder() .setNameFormat("DiscoveryClient-%d") .setDaemon(true) .build()); heartbeatExecutor = new ThreadPoolExecutor( 1, clientConfig.getHeartbeatExecutorThreadPoolSize(), 0, TimeUnit.SECONDS, new SynchronousQueue<Runnable>(), new ThreadFactoryBuilder() .setNameFormat("DiscoveryClient-HeartbeatExecutor-%d") .setDaemon(true) .build() ); // use direct handoff cacheRefreshExecutor = new ThreadPoolExecutor( 1, clientConfig.getCacheRefreshExecutorThreadPoolSize(), 0, TimeUnit.SECONDS, new SynchronousQueue<Runnable>(), new ThreadFactoryBuilder() .setNameFormat("DiscoveryClient-CacheRefreshExecutor-%d") .setDaemon(true) .build() ); // use direct handoff eurekaTransport = new EurekaTransport(); scheduleServerEndpointTask(eurekaTransport, args); AzToRegionMapper azToRegionMapper; if (clientConfig.shouldUseDnsForFetchingServiceUrls()) { azToRegionMapper = new DNSBasedAzToRegionMapper(clientConfig); } else { azToRegionMapper = new PropertyBasedAzToRegionMapper(clientConfig); } if (null != remoteRegionsToFetch.get()) { azToRegionMapper.setRegionsToFetch(remoteRegionsToFetch.get().split(",")); } instanceRegionChecker = new InstanceRegionChecker(azToRegionMapper, clientConfig.getRegion()); } catch (Throwable e) { throw new RuntimeException("Failed to initialize DiscoveryClient!", e); } // 5. 若开启了 fetch-registry 执行 if (clientConfig.shouldFetchRegistry()) { try { // 6. **重点方法 fetchRegistry**, 拉取 server 注册表信息 boolean primaryFetchRegistryResult = fetchRegistry(false); if (!primaryFetchRegistryResult) { logger.info("Initial registry fetch from primary servers failed"); } boolean backupFetchRegistryResult = true; if (!primaryFetchRegistryResult && !fetchRegistryFromBackup()) { backupFetchRegistryResult = false; logger.info("Initial registry fetch from backup servers failed"); } if (!primaryFetchRegistryResult && !backupFetchRegistryResult && clientConfig.shouldEnforceFetchRegistryAtInit()) { throw new IllegalStateException("Fetch registry error at startup. Initial fetch failed."); } } catch (Throwable th) { logger.error("Fetch registry error at startup: {}", th.getMessage()); throw new IllegalStateException(th); } } // call and execute the pre registration handler before all background tasks (inc registration) is started if (this.preRegistrationHandler != null) { this.preRegistrationHandler.beforeRegistration(); } // 6. 若开启了 register-with-eureka 执行 if (clientConfig.shouldRegisterWithEureka() && clientConfig.shouldEnforceRegistrationAtInit()) { try { if (!register() ) { // 7. **重点方法 register**, 向 server 发起注册请 throw new IllegalStateException("Registration error at startup. Invalid server response."); } } catch (Throwable th) { logger.error("Registration error at startup: {}", th.getMessage()); throw new IllegalStateException(th); } } // 8. **重点方法 initScheduledTasks** 初始化各调度任务 initScheduledTasks(); try { Monitors.registerObject(this); } catch (Throwable e) { logger.warn("Cannot register timers", e); } // This is a bit of hack to allow for existing code using DiscoveryManager.getInstance() // to work with DI'd DiscoveryClient DiscoveryManager.getInstance().setDiscoveryClient(this); DiscoveryManager.getInstance().setEurekaClientConfig(config); initTimestampMs = System.currentTimeMillis(); initRegistrySize = this.getApplications().size(); registrySize = initRegistrySize; logger.info("Discovery Client initialized at timestamp {} with initial instances count: {}", initTimestampMs, initRegistrySize); }上面提到几个重点方法, fetchRegistry 和 register, 还有 initScheduledTasks, 我们来康康他们:
-
fetchRegistry 拉取注册表
private boolean fetchRegistry(boolean forceFullRegistryFetch) { Stopwatch tracer = FETCH_REGISTRY_TIMER.start(); try { // 1. 获取缓存中数据, 第一次进来为空 Applications applications = getApplications(); // 2. 判断是否需要拉取全量数据, 覆盖缓存 if (clientConfig.shouldDisableDelta() // 开启 disable-delta // 开启 registry-refresh-single-vip-address || (!Strings.isNullOrEmpty(clientConfig.getRegistryRefreshSingleVipAddress())) || forceFullRegistryFetch // false || (applications == null) // 第一次进方法时, 需要初始化 || (applications.getRegisteredApplications().size() == 0) // 缓存为空 || (applications.getVersion() == -1)) // 好似已经被弃用 { logger.info("Disable delta property : {}", clientConfig.shouldDisableDelta()); logger.info("Single vip registry refresh property : {}", clientConfig.getRegistryRefreshSingleVipAddress()); logger.info("Force full registry fetch : {}", forceFullRegistryFetch); logger.info("Application is null : {}", (applications == null)); logger.info("Registered Applications size is zero : {}", (applications.getRegisteredApplications().size() == 0)); logger.info("Application version is -1: {}", (applications.getVersion() == -1)); getAndStoreFullRegistry(); // 3. 获取全量数据 } else { // 3. 获取增量数据 getAndUpdateDelta(applications); } applications.setAppsHashCode(applications.getReconcileHashCode()); logTotalInstances(); } catch (Throwable e) { logger.error(PREFIX + "{} - was unable to refresh its cache! status = {}", appPathIdentifier, e.getMessage(), e); return false; } finally { if (tracer != null) { tracer.stop(); } } // Notify about cache refresh before updating the instance remote status onCacheRefreshed(); // Update remote status based on refreshed data held in the cache updateInstanceRemoteStatus(); // registry was fetched successfully, so return true return true; }
先来看看获取增量的代码: `com.netflix.discovery.DiscoveryClient#getAndUpdateDelta` ```java private void getAndUpdateDelta(Applications applications) throws Throwable { // 1. 获取当前注册表版本号 long currentUpdateGeneration = fetchRegistryGeneration.get(); Applications delta = null; // 2. 请求 server 的 apps/delta 获取增量数据(jerseyClient 实现) EurekaHttpResponse<Applications> httpResponse = eurekaTransport.queryClient.getDelta(remoteRegionsRef.get()); if (httpResponse.getStatusCode() == Status.OK.getStatusCode()) { delta = httpResponse.getEntity(); } // 3. 下面更新的代码就不讲了, 充分利用了 JUC if (delta == null) { logger.warn("The server does not allow the delta revision to be applied because it is not safe. " + "Hence got the full registry."); getAndStoreFullRegistry(); } else if (fetchRegistryGeneration.compareAndSet(currentUpdateGeneration, currentUpdateGeneration + 1)) { logger.debug("Got delta update with apps hashcode {}", delta.getAppsHashCode()); String reconcileHashCode = ""; if (fetchRegistryUpdateLock.tryLock()) { try { updateDelta(delta); reconcileHashCode = getReconcileHashCode(applications); } finally { fetchRegistryUpdateLock.unlock(); } } else { logger.warn("Cannot acquire update lock, aborting getAndUpdateDelta"); } // There is a diff in number of instances for some reason if (!reconcileHashCode.equals(delta.getAppsHashCode()) || clientConfig.shouldLogDeltaDiff()) { reconcileAndLogDifference(delta, reconcileHashCode); // this makes a remoteCall } } else { logger.warn("Not updating application delta as another thread is updating it already"); logger.debug("Ignoring delta update with apps hashcode {}, as another thread is updating it already", delta.getAppsHashCode()); } }再来看看获取全量的代码:
private void getAndStoreFullRegistry() throws Throwable { // 1. 获取当前注册表版本号 long currentUpdateGeneration = fetchRegistryGeneration.get(); logger.info("Getting all instance registry info from the eureka server"); Applications apps = null; // 2. 判断是否配置了 registry-refresh-single-vip-address, 只对 VIP 感兴趣 // 未配置则请求 server 的 apps/ 接口获取全量注册表 EurekaHttpResponse<Applications> httpResponse = clientConfig.getRegistryRefreshSingleVipAddress() == null ? eurekaTransport.queryClient.getApplications(remoteRegionsRef.get()) : eurekaTransport.queryClient.getVip(clientConfig.getRegistryRefreshSingleVipAddress(), remoteRegionsRef.get()); if (httpResponse.getStatusCode() == Status.OK.getStatusCode()) { apps = httpResponse.getEntity(); } logger.info("The response status is {}", httpResponse.getStatusCode()); if (apps == null) { logger.error("The application is null for some reason. Not storing this information"); } else if (fetchRegistryGeneration.compareAndSet(currentUpdateGeneration, currentUpdateGeneration + 1)) { localRegionApps.set(this.filterAndShuffle(apps)); logger.debug("Got full registry with apps hashcode {}", apps.getAppsHashCode()); } else { logger.warn("Not updating applications as another thread is updating it already"); } }拉取服务的代码看完啦, 接着看看 register 注册服务
2. register 注册服务
com.netflix.discovery.DiscoveryClient#registerboolean register() throws Throwable { logger.info(PREFIX + "{}: registering service...", appPathIdentifier); EurekaHttpResponse<Void> httpResponse; try { // 1. 请求 server 的 apps/{appname} 注册服务 httpResponse = eurekaTransport.registrationClient.register(instanceInfo); } catch (Exception e) { logger.warn(PREFIX + "{} - registration failed {}", appPathIdentifier, e.getMessage(), e); throw e; } if (logger.isInfoEnabled()) { logger.info(PREFIX + "{} - registration status: {}", appPathIdentifier, httpResponse.getStatusCode()); } return httpResponse.getStatusCode() == Status.NO_CONTENT.getStatusCode(); }-
initScheduledTasks 初始化调度任务
private void initScheduledTasks() { // 1. 若开启了 fetch-registry 执行此定时任务 if (clientConfig.shouldFetchRegistry()) { // 2. 获取 registry-fetch-intereval-seconds 配置 int registryFetchIntervalSeconds = clientConfig.getRegistryFetchIntervalSeconds(); int expBackOffBound = clientConfig.getCacheRefreshExecutorExponentialBackOffBound(); cacheRefreshTask = new TimedSupervisorTask( "cacheRefresh", scheduler, cacheRefreshExecutor, registryFetchIntervalSeconds, TimeUnit.SECONDS, expBackOffBound, // 3. 创建一个定时任务, 执行 **CacheRefreshThread** 业务 new CacheRefreshThread() ); scheduler.schedule( cacheRefreshTask, // 4. 使用上面取得的配置时间间隔执行 registryFetchIntervalSeconds, TimeUnit.SECONDS); } // 5. 若开启了 register-with-eureka 执行此定时任务 if (clientConfig.shouldRegisterWithEureka()) { // 6. 获取 lease-renewal-interval-in-seconds 配置 int renewalIntervalInSecs = instanceInfo.getLeaseInfo().getRenewalIntervalInSecs(); int expBackOffBound = clientConfig.getHeartbeatExecutorExponentialBackOffBound(); logger.info("Starting heartbeat executor: " + "renew interval is: {}", renewalIntervalInSecs); heartbeatTask = new TimedSupervisorTask( "heartbeat", scheduler, heartbeatExecutor, renewalIntervalInSecs, TimeUnit.SECONDS, expBackOffBound, // 7. 创建定时任务, 执行 **HeartbeatThread** 任务 new HeartbeatThread() ); scheduler.schedule( heartbeatTask, / 8. 使用上面取得的心跳间隔执行 renewalIntervalInSecs, TimeUnit.SECONDS); // InstanceInfo replicator instanceInfoReplicator = new InstanceInfoReplicator( this, instanceInfo, clientConfig.getInstanceInfoReplicationIntervalSeconds(), 2); // burstSize statusChangeListener = new ApplicationInfoManager.StatusChangeListener() { @Override public String getId() { return "statusChangeListener"; } @Override public void notify(StatusChangeEvent statusChangeEvent) { if (InstanceStatus.DOWN == statusChangeEvent.getStatus() || InstanceStatus.DOWN == statusChangeEvent.getPreviousStatus()) { // log at warn level if DOWN was involved logger.warn("Saw local status change event {}", statusChangeEvent); } else { logger.info("Saw local status change event {}", statusChangeEvent); } instanceInfoReplicator.onDemandUpdate(); } }; if (clientConfig.shouldOnDemandUpdateStatusChange()) { applicationInfoManager.registerStatusChangeListener(statusChangeListener); } instanceInfoReplicator.start(clientConfig.getInitialInstanceInfoReplicationIntervalSeconds()); } else { logger.info("Not registering with Eureka server per configuration"); } }上面提到了两个任务, 分别是 CacheRefreshThread 和 HeartbeatThread, 我们看看具体的执行代码:
-
CacheRefreshThread
class CacheRefreshThread implements Runnable { public void run() { // 掉了外部类的方法 refreshRegistry(); } } @VisibleForTesting void refreshRegistry() { try { boolean isFetchingRemoteRegionRegistries = isFetchingRemoteRegionRegistries(); boolean remoteRegionsModified = false; // This makes sure that a dynamic change to remote regions to fetch is honored. String latestRemoteRegions = clientConfig.fetchRegistryForRemoteRegions(); if (null != latestRemoteRegions) { String currentRemoteRegions = remoteRegionsToFetch.get(); if (!latestRemoteRegions.equals(currentRemoteRegions)) { // Both remoteRegionsToFetch and AzToRegionMapper.regionsToFetch need to be in sync synchronized (instanceRegionChecker.getAzToRegionMapper()) { if (remoteRegionsToFetch.compareAndSet(currentRemoteRegions, latestRemoteRegions)) { String[] remoteRegions = latestRemoteRegions.split(","); remoteRegionsRef.set(remoteRegions); instanceRegionChecker.getAzToRegionMapper().setRegionsToFetch(remoteRegions); remoteRegionsModified = true; } else { logger.info("Remote regions to fetch modified concurrently," + " ignoring change from {} to {}", currentRemoteRegions, latestRemoteRegions); } } } else { // Just refresh mapping to reflect any DNS/Property change instanceRegionChecker.getAzToRegionMapper().refreshMapping(); } } // 1. **定时执行 fetchRegistry**, 之前讲过这个方法!! boolean success = fetchRegistry(remoteRegionsModified); if (success) { registrySize = localRegionApps.get().size(); // 2. 成功则更新最后成功更新时间戳 lastSuccessfulRegistryFetchTimestamp = System.currentTimeMillis(); } if (logger.isDebugEnabled()) { StringBuilder allAppsHashCodes = new StringBuilder(); allAppsHashCodes.append("Local region apps hashcode: "); allAppsHashCodes.append(localRegionApps.get().getAppsHashCode()); allAppsHashCodes.append(", is fetching remote regions? "); allAppsHashCodes.append(isFetchingRemoteRegionRegistries); for (Map.Entry<String, Applications> entry : remoteRegionVsApps.entrySet()) { allAppsHashCodes.append(", Remote region: "); allAppsHashCodes.append(entry.getKey()); allAppsHashCodes.append(" , apps hashcode: "); allAppsHashCodes.append(entry.getValue().getAppsHashCode()); } logger.debug("Completed cache refresh task for discovery. All Apps hash code is {} ", allAppsHashCodes); } } catch (Throwable e) { logger.error("Cannot fetch registry from server", e); } } -
HeartbeatThread
private class HeartbeatThread implements Runnable { public void run() { if (renew()) { // 1. 调用 renew 方法发起续约 // 2. 更新最后成功续约的时间戳 lastSuccessfulHeartbeatTimestamp = System.currentTimeMillis(); } } } boolean renew() { EurekaHttpResponse<InstanceInfo> httpResponse; try { // 2. 向 server 的 apps/{appName}/{id} 接口发起续约请求 httpResponse = eurekaTransport.registrationClient.sendHeartBeat(instanceInfo.getAppName(), instanceInfo.getId(), instanceInfo, null); logger.debug(PREFIX + "{} - Heartbeat status: {}", appPathIdentifier, httpResponse.getStatusCode()); // 3. 如果服务端没有找到本服务 if (httpResponse.getStatusCode() == Status.NOT_FOUND.getStatusCode()) { REREGISTER_COUNTER.increment(); logger.info(PREFIX + "{} - Re-registering apps/{}", appPathIdentifier, instanceInfo.getAppName()); long timestamp = instanceInfo.setIsDirtyWithTime(); // 4. 注册, 上面也讲过这个方法 boolean success = register(); if (success) { instanceInfo.unsetIsDirty(timestamp); } return success; } return httpResponse.getStatusCode() == Status.OK.getStatusCode(); } catch (Throwable e) { logger.error(PREFIX + "{} - was unable to send heartbeat!", appPathIdentifier, e); return false; } }
-
2) EurekaClient 服务下线
我们回顾一下 EurekaClientAUtoConfiguration 中的 eurekaClient 方法:
org.springframework.cloud.netflix.eureka.EurekaClientAutoConfiguration.EurekaClientConfiguration#eurekaClient
@Bean(destroyMethod = "shutdown")
@ConditionalOnMissingBean(value = EurekaClient.class,
search = SearchStrategy.CURRENT)
public EurekaClient eurekaClient(ApplicationInfoManager manager,
EurekaClientConfig config) {
return new CloudEurekaClient(manager, config, this.optionalArgs,
this.context);
}在 Java 应用正常关闭时, 会触发这个 shutdown 方法进行下线逻辑, 我们其实也可以手动去调用它手动下线服务:
com.netflix.discovery.DiscoveryClient#shutdown
@PreDestroy
@Override
public synchronized void shutdown() {
if (isShutdown.compareAndSet(false, true)) {
logger.info("Shutting down DiscoveryClient ...");
if (statusChangeListener != null && applicationInfoManager != null) {
applicationInfoManager.unregisterStatusChangeListener(statusChangeListener.getId());
}
// 1. 将之前提到的两个定时任务取消
cancelScheduledTasks();
// 2. 如果开启注册到 server, 则将自己状态改为 DOWN, 发送下线请求
if (applicationInfoManager != null
&& clientConfig.shouldRegisterWithEureka()
&& clientConfig.shouldUnregisterOnShutdown()) {
applicationInfoManager.setInstanceStatus(InstanceStatus.DOWN);
unregister();
}
// 3. 一些监控正常 shutdown
if (eurekaTransport != null) {
eurekaTransport.shutdown();
}
heartbeatStalenessMonitor.shutdown();
registryStalenessMonitor.shutdown();
Monitors.unregisterObject(this);
logger.info("Completed shut down of DiscoveryClient");
}
}Eureka Server 源码(服务接口)
本文采用知识共享 署名-相同方式共享 4.0 国际 许可协议进行许可。
访问 https://creativecommons.org/licenses/by-sa/4.0/ 查看该许可协议。
Eureka Server 源码(服务接口)
本文基于上游最新 RELEASE 版, SpringBoot 2.2.5, SpringCloud Hoxton.SR8 撰写
观察 EurekaServer 的启动流程可以发现, 仪表盘的 WEB 服务, 是由 SpringMVC 提供的, 但是除了 SpringMVC, EurekaServer 还加载了 Jersey 发布 Restful 服务, 处理客户端请求, 我们先来看看加载 Bean 时的两个核心方法:
private static final String[] EUREKA_PACKAGES = new String[] {
"com.netflix.discovery", "com.netflix.eureka" };
@Bean
public javax.ws.rs.core.Application jerseyApplication(Environment environment,
ResourceLoader resourceLoader) {
// 1. 扫描器实例创建
ClassPathScanningCandidateComponentProvider provider = new ClassPathScanningCandidateComponentProvider(
false, environment);
// 2. 定义需要扫描的注解
provider.addIncludeFilter(new AnnotationTypeFilter(Path.class));
provider.addIncludeFilter(new AnnotationTypeFilter(Provider.class));
// 3. 扫描指定包并将对象 put 进 classes 中
Set<Class<?>> classes = new HashSet<>();
for (String basePackage : EUREKA_PACKAGES) {
Set<BeanDefinition> beans = provider.findCandidateComponents(basePackage);
for (BeanDefinition bd : beans) {
Class<?> cls = ClassUtils.resolveClassName(bd.getBeanClassName(),
resourceLoader.getClassLoader());
classes.add(cls);
}
}
// 4. 资源文件相关配置
Map<String, Object> propsAndFeatures = new HashMap<>();
propsAndFeatures.put(
// Skip static content used by the webapp
ServletContainer.PROPERTY_WEB_PAGE_CONTENT_REGEX,
EurekaConstants.DEFAULT_PREFIX + "/(fonts|images|css|js)/.*");
DefaultResourceConfig rc = new DefaultResourceConfig(classes);
rc.setPropertiesAndFeatures(propsAndFeatures);
return rc;
}
@Bean
public FilterRegistrationBean<?> jerseyFilterRegistration(
javax.ws.rs.core.Application eurekaJerseyApp) { // 1. 注入上个个方法的实例
FilterRegistrationBean<Filter> bean = new FilterRegistrationBean<Filter>();
bean.setFilter(new ServletContainer(eurekaJerseyApp));
bean.setOrder(Ordered.LOWEST_PRECEDENCE);
bean.setUrlPatterns(
Collections.singletonList(EurekaConstants.DEFAULT_PREFIX + "/*"));
return bean;
}通过上述源码得知, EurekaServer 配置 Jersey 会扫描 com.netflix.discovery 和 com.netflix.eureka 包下, 包含 @Path 和 @Provider 注解的类注册为 WEB 服务, 我们来看看主要的几个接口:
1) ApplicationResource.addInstance 注册服务
com.netflix.eureka.resources.ApplicationResource#addInstance
@POST
@Consumes({"application/json", "application/xml"})
public Response addInstance(InstanceInfo info,
@HeaderParam(PeerEurekaNode.HEADER_REPLICATION) String isReplication) {
logger.debug("Registering instance {} (replication={})", info.getId(), isReplication);
// 1. 实例参数校验
if (isBlank(info.getId())) {
return Response.status(400).entity("Missing instanceId").build();
} else if (isBlank(info.getHostName())) {
return Response.status(400).entity("Missing hostname").build();
} else if (isBlank(info.getIPAddr())) {
return Response.status(400).entity("Missing ip address").build();
} else if (isBlank(info.getAppName())) {
return Response.status(400).entity("Missing appName").build();
} else if (!appName.equals(info.getAppName())) {
return Response.status(400).entity("Mismatched appName, expecting " + appName + " but was " + info.getAppName()).build();
} else if (info.getDataCenterInfo() == null) {
return Response.status(400).entity("Missing dataCenterInfo").build();
} else if (info.getDataCenterInfo().getName() == null) {
return Response.status(400).entity("Missing dataCenterInfo Name").build();
}
// 2. 错误数据纠正处理
DataCenterInfo dataCenterInfo = info.getDataCenterInfo();
if (dataCenterInfo instanceof UniqueIdentifier) {
String dataCenterInfoId = ((UniqueIdentifier) dataCenterInfo).getId();
if (isBlank(dataCenterInfoId)) {
boolean experimental = "true".equalsIgnoreCase(serverConfig.getExperimental("registration.validation.dataCenterInfoId"));
if (experimental) {
String entity = "DataCenterInfo of type " + dataCenterInfo.getClass() + " must contain a valid id";
return Response.status(400).entity(entity).build();
} else if (dataCenterInfo instanceof AmazonInfo) {
AmazonInfo amazonInfo = (AmazonInfo) dataCenterInfo;
String effectiveId = amazonInfo.get(AmazonInfo.MetaDataKey.instanceId);
if (effectiveId == null) {
amazonInfo.getMetadata().put(AmazonInfo.MetaDataKey.instanceId.getName(), info.getId());
}
} else {
logger.warn("Registering DataCenterInfo of type {} without an appropriate id", dataCenterInfo.getClass());
}
}
}
// 3. 注册
registry.register(info, "true".equals(isReplication));
return Response.status(204).build(); // 204 to be backwards compatible
}我们接着第 3 步注册方法往里走(只看集群实现):
com.netflix.eureka.registry.PeerAwareInstanceRegistryImpl#register
@Override
public void register(final InstanceInfo info, final boolean isReplication) {
// 1. 服务失效事件设置, 客户端未配置则使用默认
int leaseDuration = Lease.DEFAULT_DURATION_IN_SECS;
if (info.getLeaseInfo() != null && info.getLeaseInfo().getDurationInSecs() > 0) {
leaseDuration = info.getLeaseInfo().getDurationInSecs();
}
// 2. 注册服务
super.register(info, leaseDuration, isReplication);
// 3. 将服务复制给其他对等节点
replicateToPeers(Action.Register, info.getAppName(), info.getId(), info, null, isReplication);
}注册的方法我们就不看了, 接着看看第 3 步的复制代码:
private void replicateToPeers(Action action, String appName, String id,
InstanceInfo info /* optional */,
InstanceStatus newStatus /* optional */, boolean isReplication) {
// 1. 监控相关
Stopwatch tracer = action.getTimer().start();
try {
if (isReplication) {
numberOfReplicationsLastMin.increment();
}
// 如已复制则不走了
if (peerEurekaNodes == Collections.EMPTY_LIST || isReplication) {
return;
}
// 2. 遍历所有对等节点
for (final PeerEurekaNode node : peerEurekaNodes.getPeerEurekaNodes()) {
// 3. 如果遍历到自己, 忽略
if (peerEurekaNodes.isThisMyUrl(node.getServiceUrl())) {
continue;
}
// 4. 复制给对等节点
replicateInstanceActionsToPeers(action, appName, id, info, newStatus, node);
}
} finally {
tracer.stop();
}
}
private void replicateInstanceActionsToPeers(Action action, String appName,
String id, InstanceInfo info, InstanceStatus newStatus,
PeerEurekaNode node) {
try {
InstanceInfo infoFromRegistry;
CurrentRequestVersion.set(Version.V2);
switch (action) {
case Cancel: // 取消实例
node.cancel(appName, id);
break;
case Heartbeat: // 心跳续约
InstanceStatus overriddenStatus = overriddenInstanceStatusMap.get(id);
infoFromRegistry = getInstanceByAppAndId(appName, id, false);
node.heartbeat(appName, id, infoFromRegistry, overriddenStatus, false);
break;
case Register: // 注册实例
node.register(info);
break;
case StatusUpdate: // 状态更新
infoFromRegistry = getInstanceByAppAndId(appName, id, false);
node.statusUpdate(appName, id, newStatus, infoFromRegistry);
break;
case DeleteStatusOverride: // 删除覆盖状态
infoFromRegistry = getInstanceByAppAndId(appName, id, false);
node.deleteStatusOverride(appName, id, infoFromRegistry);
break;
}
} catch (Throwable t) {
logger.error("Cannot replicate information to {} for action {}", node.getServiceUrl(), action.name(), t);
} finally {
CurrentRequestVersion.remove();
}
}2) InstanceResource.renewLease 续约服务实例
com.netflix.eureka.resources.InstanceResource#renewLease
@PUT
public Response renewLease(
@HeaderParam(PeerEurekaNode.HEADER_REPLICATION) String isReplication,
@QueryParam("overriddenstatus") String overriddenStatus,
@QueryParam("status") String status,
@QueryParam("lastDirtyTimestamp") String lastDirtyTimestamp) {
boolean isFromReplicaNode = "true".equals(isReplication);
// **核心方法**
boolean isSuccess = registry.renew(app.getName(), id, isFromReplicaNode);
if (!isSuccess) {
logger.warn("Not Found (Renew): {} - {}", app.getName(), id);
return Response.status(Status.NOT_FOUND).build();
}
Response response;
if (lastDirtyTimestamp != null && serverConfig.shouldSyncWhenTimestampDiffers()) {
response = this.validateDirtyTimestamp(Long.valueOf(lastDirtyTimestamp), isFromReplicaNode);
// Store the overridden status since the validation found out the node that replicates wins
if (response.getStatus() == Response.Status.NOT_FOUND.getStatusCode()
&& (overriddenStatus != null)
&& !(InstanceStatus.UNKNOWN.name().equals(overriddenStatus))
&& isFromReplicaNode) {
registry.storeOverriddenStatusIfRequired(app.getAppName(), id, InstanceStatus.valueOf(overriddenStatus));
}
} else {
response = Response.ok().build();
}
logger.debug("Found (Renew): {} - {}; reply status={}", app.getName(), id, response.getStatus());
return response;
}com.netflix.eureka.registry.PeerAwareInstanceRegistryImpl#renew
public boolean renew(final String appName, final String id, final boolean isReplication) {
if (super.renew(appName, id, isReplication)) { // 1. 续约
// 2. 复制给对等节点
replicateToPeers(Action.Heartbeat, appName, id, null, null, isReplication);
return true;
}
return false;
}com.netflix.eureka.registry.AbstractInstanceRegistry#renew
public boolean renew(String appName, String id, boolean isReplication) {
RENEW.increment(isReplication);
// 1. 获取服务实例集合
Map<String, Lease<InstanceInfo>> gMap = registry.get(appName);
Lease<InstanceInfo> leaseToRenew = null;
if (gMap != null) {
leaseToRenew = gMap.get(id); // 2. 获取实例
}
if (leaseToRenew == null) {
RENEW_NOT_FOUND.increment(isReplication);
logger.warn("DS: Registry: lease doesn't exist, registering resource: {} - {}", appName, id);
return false;
} else {
InstanceInfo instanceInfo = leaseToRenew.getHolder();
if (instanceInfo != null) {
// 3. 获取实例状态, 不正常处理
InstanceStatus overriddenInstanceStatus = this.getOverriddenInstanceStatus(
instanceInfo, leaseToRenew, isReplication);
if (overriddenInstanceStatus == InstanceStatus.UNKNOWN) {
logger.info("Instance status UNKNOWN possibly due to deleted override for instance {}"
+ "; re-register required", instanceInfo.getId());
RENEW_NOT_FOUND.increment(isReplication);
return false;
}
if (!instanceInfo.getStatus().equals(overriddenInstanceStatus)) {
logger.info(
"The instance status {} is different from overridden instance status {} for instance {}. "
+ "Hence setting the status to overridden status", instanceInfo.getStatus().name(),
instanceInfo.getOverriddenStatus().name(),
instanceInfo.getId());
instanceInfo.setStatusWithoutDirty(overriddenInstanceStatus);
}
}
renewsLastMin.increment();
leaseToRenew.renew(); // 4. **核心方法**
return true;
}
}com.netflix.eureka.lease.Lease#renew
public void renew() {
lastUpdateTimestamp = System.currentTimeMillis() + duration;
}服务续约本质上就是: 将注册表内的服务实例的 lastUpdateTimestamp 最后更新时间戳刷新一下仅此而已
